Most commercial roof leaks in Calgary don’t start in the middle of the membrane—they start at the edges and transitions. That means flashings.
Flashings are what connect your roof to walls, parapets, curbs, drains, and penetrations. When they fail, water has a direct path into the building. In Calgary’s climate, with Chinooks, freeze–thaw cycles, hail, and heavy snow, flashing failures are the #1 source of commercial roof leaks.
This guide explains what flashing failures look like, why they happen so often in Calgary, and how to fix and prevent them with proper design, inspections, and maintenance—plus how CMP Roofing ties flashing work into leak repair, drainage, maintenance plans, and long-term asset management.
For an overview of commercial and industrial roofing services, visit:
https://cmproofing.ca/services/
You can also browse related technical articles at:
https://cmproofing.ca/blog/
What Are Roof Flashings and Why Do They Matter So Much?
Flashings are the parts of the roof system that:
- Transition between horizontal surfaces and vertical surfaces
- Seal around penetrations and edges
- Tie the main membrane into walls, parapets, curbs, drains, and edges
Common commercial flashing locations:
- Parapet walls and perimeter edges
- Roof-to-wall transitions and façade interfaces
- Around rooftop mechanical curbs, hatches, skylights, and vents
- Drains, scuppers, and gutters
- Expansion joints between building sections
Your roof membrane might be in good shape, but if the flashings at these locations are failing, water can bypass everything and go straight into the building.
For what inspectors look at around flashings, see:
“Calgary Commercial Roof Inspection Checklist: What Inspectors Look For & When You Need One”
https://cmproofing.ca/blog/
Why Flashings Fail So Often on Calgary Commercial Roofs
Flashings sit exactly where building movement, thermal stress, and weather forces are at their worst.
1. Calgary’s Freeze–Thaw & Chinooks
Repeated cycles of freezing, thawing, and rapid temperature changes:
- Expand and contract materials at corners and transitions
- Open up tiny gaps at terminations and laps
- Stress sealants, mastics, and caulking until they crack or pull away
The result: small gaps around flashings that become leak paths.
For a climate-focused overview, see:
“How Calgary’s Weather (Hail, Chinooks & Freeze–Thaw) Impacts Flat Roof Systems”
https://cmproofing.ca/blog/
2. Building Movement & Settlement
Flashings are installed where:
- Walls meet roofs
- Different building sections join
- Slab edges and parapets move slightly with load, temperature, and time
Even small movements can:
- Break brittle sealant joints
- Pull membrane away from upstands or term bars
- Create cracks where water can be driven in by wind
3. Water Concentration at Details
Flashings often sit in high-flow water zones:
- At drains and scuppers
- At inside corners in parapet walls
- Around mechanical curbs where water ponds
If drainage isn’t designed or maintained properly, water sits against flashings and accelerates deterioration.
For more on drainage and ponding issues, see:
“Flat Roof Drainage Problems in Calgary: Ponding, Freeze–Thaw Damage & Permanent Fixes”
https://cmproofing.ca/blog/
4. Mechanical and Trade Damage
Flashings are frequently damaged by:
- Mechanical trades working at rooftop units
- Cable/telecom installations and removals
- Snow removal on roofs and around parapets
- Improvised access routes across parapets and edges
This is especially common on industrial and high-traffic roofs. For those contexts, see:
“Calgary Industrial Roofing: Handling Chemical, Heat & Exhaust Exposure on Flat Roofs”
https://cmproofing.ca/blog/
The Most Common Flashing Failure Points on Calgary Commercial Roofs
Parapet & Edge Flashings
Typical issues:
- Membrane or cap sheet splitting at the inside corner where horizontal and vertical surfaces meet
- Metal copings that are loose, open at joints, or poorly lapped
- Water blowing under or behind edge metal where terminations are weak
Consequences:
- Leaks along exterior walls and at the top of interior demising walls
- Stains and damage in perimeter offices or retail spaces
Related guidance for edge and façade issues:
“Preventing Roof Leaks in Calgary Retail Plazas: Common Weak Points & Fixes”
https://cmproofing.ca/blog/
Roof-to-Wall Transitions
Typical issues:
- Terminations that are too low or not properly sealed
- Incompatible sealants bridging between different materials
- Cladding or façade systems directing water behind flashings
Consequences:
- Hidden moisture inside wall cavities
- Leaks that appear far from the actual failure point
Mechanical Curbs & Penetrations
Typical issues:
- Poorly detailed or aged curb flashings around RTUs, vents, and hatches
- Unsealed or modified penetrations by mechanical trades
- Ponding water around curbs due to poor slope or blocked drains
Consequences:
- Leaks right over sensitive equipment, production areas, or tenant spaces
- Chronic recurring leaks in “mystery spots” near units
These issues are especially visible in warehouses, industrial plants, and medical facilities. See:
“Commercial Roofing for Calgary Warehouses: Design, Drainage & Dock Area Details”
“Calgary Medical & Healthcare Facility Roofing: Infection Control, Redundancy & Risk Planning”
https://cmproofing.ca/blog/
Drains, Scuppers & Gutters
Typical issues:
- Membrane or flashing pulled back from drain bowls or scupper boxes
- Cracked sealant around metal inserts and strainers
- Poor transitions between roof membrane and gutter systems
Consequences:
- Leaks directly below drain locations
- Water backing up into the roof assembly
For detailed drainage discussion, see:
“Flat Roof Drainage Problems in Calgary: Ponding, Freeze–Thaw Damage & Permanent Fixes”
https://cmproofing.ca/blog/
Expansion Joints
Typical issues:
- Cracked or deteriorated expansion joint covers
- Membrane tie-ins to joint systems failing or separating
- Water tracking along joint lines and entering at low points
Consequences:
- Leaks that show up along interior cracks or transitions between building sections
How to Diagnose Flashing Failures Properly
When you see a leak inside, it’s tempting to assume the membrane above is the problem. In reality, your roofer should focus heavily on flashing zones.
A proper flashing-focused inspection includes:
- Tracing interior leak location relative to exterior walls, curbs, and drains
- Checking all upstands, corners, and penetrations uphill from the leak
- Probing seams, terminations, and sealant joints for movement or gaps
- Looking for ponding patterns and debris build-up around details
Most of this falls under a thorough commercial roof inspection. For a structured checklist, see:
“Calgary Commercial Roof Inspection Checklist: What Inspectors Look For & When You Need One”
https://cmproofing.ca/blog/
Regular inspections also tie into:
“How Often Should You Inspect Your Commercial Roof in Calgary? Annual, Seasonal & Post-Storm Schedules”
https://cmproofing.ca/blog/
Repair Options: Fixing Flashing Failures the Right Way
Not all flashing problems require a full roof replacement. But they do require methodical, high-quality repairs—not just more caulking.
Temporary vs Permanent Repairs
Temporary measures (for active leak events):
- Localized sealant or mastic applications to stop water ingress
- Emergency patches around obvious splits or openings
- Tarps or protection in extreme weather events
These should be treated as short-term emergency controls only.
For immediate leak response practices, see:
“Calgary Commercial Roof Leak Repair: What Facility Managers Should Do in the First 24 Hours”
“Emergency Roof Leak Repair in Calgary: 24/7 Process, Response Times & What It Costs”
https://cmproofing.ca/blog/
Permanent repairs typically involve:
- Removing failed flashing materials back to solid, sound substrate
- Installing new properly detailed flashing plies and counterflashings
- Correcting local slope or adding crickets to prevent water from sitting at details
- Replacing or re-fastening metal copings and edge flashings correctly
Flashing Rebuilds During Restoration or Replacement
If flashing failures are widespread or the roof is older, it may be more cost-effective to:
- Complete a comprehensive flashing rebuild as part of a restoration or overlay, or
- Replace the roof system entirely and rebuild flashing details to current best practices
Decision frameworks for restoration vs replacement:
- “Commercial Roof Replacement vs Restoration in Calgary: Coatings, Overlays or Tear-Off?”
- “Commercial Roof Coatings in Calgary: Silicone vs Acrylic vs Polyurethane Compared”
- “End-of-Life Signs for Commercial Flat Roofs in Calgary: When It’s Time to Replace”
at https://cmproofing.ca/blog/
Preventing Flashing Failures: Design, Detailing & Maintenance
Design & Construction
Preventing flashing problems starts before the roof is built:
- Use flashing heights that meet or exceed manufacturer and code requirements
- Integrate flashing details with cladding, façade, and mechanical design
- Avoid “value engineering” that strips out critical cover boards, backing, or securement
- Use proven, tested assemblies and experienced commercial roofing contractors
For new construction and major replacement projects, see:
“New Construction Flat Roofing in Calgary: Design Considerations for Long-Term Performance”
https://cmproofing.ca/blog/
Inspection & Maintenance
Most flashing failures can be caught early if someone is looking for them.
A good maintenance plan:
- Prioritizes inspections at flashings, edges, and penetrations
- Addresses minor splits, open terminations, and loose metal before they leak
- Keeps drains, scuppers, and gutters clear so water doesn’t sit against flashings
- Coordinates with mechanical trades so rooftop work doesn’t compromise flashing details
For maintenance structure, see:
“Commercial Roof Maintenance Plans in Calgary: How to Extend Flat Roof Life by 10+ Years”
https://cmproofing.ca/blog/
Warranties, Documentation & Risk
Flashing failures are often where warranty and liability questions arise. To protect warranties and insurance coverage:
- Follow manufacturer guidelines for inspections and maintenance
- Document flashing repairs and upgrades with photos and reports
- Investigate and correct chronic flashing issues rather than repeatedly patching
For more on how warranties interact with real-world roof conditions, see:
“Calgary Commercial Roof Warranties Explained: What Owners & Property Managers Need to Know”
https://cmproofing.ca/blog/
Flashings in a Portfolio Context: Asset Management & Budgeting
If you manage multiple buildings—retail, office, industrial, medical, or mixed-use—flashing failures will appear again and again across the portfolio.
A portfolio-level approach helps you:
- Identify buildings with repeated flashing-related leaks
- Prioritize flashing rebuilds during planned roof projects
- Budget for targeted flashing upgrades (parapets, mechanical zones, plaza/amenity interfaces)
- Reduce the number of emergency calls by addressing root causes systematically
For an asset management framework that includes flashing and roof system planning, see:
“Roof Asset Management for Calgary Property Portfolios: Budgeting, Lifecycle & Risk Planning”
https://cmproofing.ca/blog/
How CMP Roofing Helps Fix and Prevent Flashing Failures in Calgary
CMP Roofing works with property managers, owners, condo boards, and facility teams across Calgary and surrounding areas to:
- Diagnose leaks and track them back to flashing failures
- Perform detailed commercial roof inspections with emphasis on edges and transitions
- Complete high-quality flashing repairs and rebuilds at parapets, walls, curbs, drains, and expansion joints
- Integrate flashing upgrades into broader maintenance, restoration, or replacement projects
- Build inspection and maintenance programs that keep flashings from becoming the weak link in your roof system
Commercial Roofing Services overview:
https://cmproofing.ca/services/
Service area coverage:
https://cmproofing.ca/locations/
Education hub (inspections, leaks, drainage, maintenance, warranties, restoration vs replacement, industrial/warehouse/retail-specific issues):
https://cmproofing.ca/blog/
Next Steps: Get Your Calgary Roof Flashings Checked Before the Next Leak
If you’re seeing:
- Recurring leaks near walls, corners, or mechanical units
- Stains in perimeter offices, retail bays, or demising walls
- Chronic leaks at drains, scuppers, or along expansion joints
- An older roof that’s been patched many times around edges and details
chances are you have flashing problems, not just membrane issues.
CMP Roofing can:
- Inspect and test your commercial roof flashings
- Provide a prioritized list of flashing repairs and upgrades
- Help you decide between targeted repairs, broader flashing rebuilds, or full roof restoration/replacement
- Build a proactive maintenance plan so flashing failures don’t stay your #1 source of leaks
To book a flashing-focused roof assessment for your Calgary property (or portfolio), contact CMP Roofing at:
https://cmproofing.ca/contact-2/
Then use the resources at https://cmproofing.ca/blog/ to dive deeper into inspections, leak response, drainage, maintenance plans, warranties, restoration vs replacement, industrial and retail roof challenges, and portfolio planning—so your roof flashings become a strength, not the weak point in your commercial roof system.
Comments are closed here.
